HP / Agilent 85133F Flexible Cable Set, 2.4 mm 85133F manufacturer from United States Recon Test Equipment Inc

HP / Agilent 85133F Flexible Cable Set, 2.4 mm


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: 85133F

Condition: Used

Brand Name: HP/Agilent

HP / Agilent 85133F Flexible Cable Set, 2.4 mm

The Agilent 85133F is a 63 cm (25 in) longflexible cable set composed of a 2.4 mm female to PSC-2.4 mm femaleconnector and a 2.4 mm femaleto 2.4 mm male connector. Cable frequency range is DC to 50 GHz with areturn loss of greater than or equal to 12.5 dB. Insertion loss is 0.48 *sqrt (f) + 0.25, where f is frequency in GHz, for the test portconnector and 3.64 dB at maximum frequency for the device connector.Phase stability of semi-rigid/flexible cables is specified with a 90degree bend using a 4 to 3 inch radius. Stability of the Agilent 85133Fis less than 0.17 dB and phase is 0.16*f + 0.8, where f is frequencymeasured in GHz.
