Infiniium DSA90000A Series addresses customer development workflow: debug, analysis, and compliance with the highest signal integrity in the industry.

Superior Signal Integrity: Infiniium 90000A provides better measurement stability and repeatability with the Industry's lowest noise floor.
Deep Application Analysis: With the ultra-responsive 1Gpts deep memory and powerful hardware-software triggering combination, you can isolate even the most complicated signal to decrease debugging and analysis time.
Infiniium DSA90000A Series provides "Better Insight" into your designs!

The DSA90000A Series is built around an Infiniium DSO90000A Series oscilloscope and includes standard 20 Mpts of memory, clock recovery and real-time eye diagrams (SDA), basic jitter and RJ/DJ separation (EZJIT+), and bandwidth/noise reduction software included in a bundle that provides you with the right set of tools to debug even the most complicated signals.

    6 GHz bandwidth
    20 GSa/s on each of 4 analog channels
    20 Mpts to 1 Gpts on each channel
    Low noise floor: 234 μVrms at 5 mV/div
    Industry's only 3-level trigger sequencing featuring the InfiniiScan software trigger
    More than 29 software applications for compliance, debugging and analysis including: DDR 1, Serial Rapid IO, USB 2.0
    12.1" XGA touch screen display
    Industry´s lowest noise floor probing system
    Highest signal fidelity InfiniiMax II probing system
    Interchangeable probe heads
    Industry´s only RoHS compliant solder-in probing solution

Options Installed:

    002 – EZJIT jitter analysis software
    003 – High-Speed SDA and clock recovery
    004 – EZJIT plus jitter analysis software
    005 – Noise Reduction and bandwidth control software
    20M – Memory - 20M memory / channel upgrade
    801 – Removable hard drive
    803 – Additional 2GB CPU memory (4 GB total)
    805 – GPIB card-interface
    821 – Additional Precision BNC to SMA adapters includes qty 2
    N5467A – User defined Application
    N5471D – Upgrade - 4 to 6 Ghz After-purchase Bandwidth
    N5475A – Transit case for 90000 Series oscilloscopes
