Rohde & Schwarz SMA100A-B20-B103 9 kHz to 3 GHz Signal Generator


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: SMA100A

Brand Name: Rohde & Schwarz

Rohde & Schwarz SMA100A-B20-B103 9 kHz to 3 GHz Signal Generator

The R&SSMA 100A combines superior signalquality with very high setting speed, which makes it ideal for any task.Whether in development, production, service or maintenance, the R&SSMA 100A does an excellent job.

In the frequency range from 9 kHzto 6 GHz, it can generate CW signals as well as all common types ofanalog modulation (AM, FM, φM, pulse modulation). Excellentspecifications and a wide range of modulation signals – these are thecharacteristic features of the R&S SMA 100A. In addition, alow-jitter clock synthesizer option supplies differential clock signalsof up to 1.5 GHz independently of the RF frequency.

Very low SSB phase noise of typ. –135 dBc
Wideband noise of typ. –160 dBc
Nonharmonics of typ. –100 dBc
Very short frequency and level setting times of <3 ms across the entire frequency and level range
Fast hopping mode with flexibly addressable frequency and level pairs, as fast as normal list mode
Frequencysetting time of typ. <10 μs within a bandwidth of 40 MHz due todirect access to the DDS-based synthesizer (with the R&S SMA-B20 or-B22 option)
Very high level accuracy and repeatability
Electronic attenuator with built-in overvoltage protection over entire frequency range
Pulse modulator with excellent characteristics (on/off ratio >80 dB, rise/fall time typ. 10 ns)
Pulse generator integrated as standard
Intuitive user interface with graphical display of signal flow (block diagram)
Remote control via GPIB or LAN
USB connectors (e.g. for keyboard, mouse, memory stick)
Selectable SCPI- or 8662A/63A-compatible IEC/IEEE bus command set
Control via remote operation tool (e.g. VNC)

Options:

SMA-B20 - FM/PhiM

SMA-B103 -Frequency range 9kHz to 3GHz with electronic attenuator.
